Model |
Model |
Unit |
| |
|
|
|
|
| 1 |
Drilling Capacity (In Steel) |
32 |
40 |
mm |
| |
|
|
|
|
| 2 |
Column Diameter |
114 |
114 |
mm |
| |
|
|
|
|
| 3 |
Center of Spindle & Column |
300 |
300 |
mm |
| |
|
|
|
|
| 4 |
Max. Distance (Nose to Base) |
625 |
625 |
mm |
| |
|
|
|
|
| 5 |
Max. Distance (Nose to Table) |
1045 |
1045 |
mm |
| |
|
|
|
|
| 6 |
Taper in Spindle |
3 |
4 |
mt |
| |
|
|
|
|
| 7 |
Spindle Travel |
170 |
200 |
mm |
| |
|
|
|
|
| 8 |
Quill-Dia Meter |
¢72 |
¢72 |
mm |
| |
|
|
|
|
| 9 |
Nos. Of Speed |
8 |
8 |
mm |
| |
|
|
|
|
| 10 |
Range of Speed |
75 to 2070 |
75 to 2070 |
mm |
| |
|
|
|
|
| 11 |
Table Size |
390 x 390 |
390 x 390 |
mm |
| |
|
|
|
|
| 12 |
Base Size (Machined area) |
390 x 390 |
390 x 390 |
mm |
| |
|
|
|
|
| 13 |
Overall Base Size |
740 x 500
x120 |
740 x 500
x120 |
mm |
| |
|
|
|
|
| 14 |
V-Belt Section |
B-58 |
B-58 |
inch |
| |
|
|
|
|
| 15 |
Electric Motor 1440Rpm |
1.5 |
1.5 |
hp |
| |
|
|
|
|
| 16 |
Wooden Case Size(L x W x H ) |
1050x600
x1900
|
1050x600
x1900 |
mm |
| |
|
|
|
|
| 17 |
Range Of Power Feed |
Fine Feed |
Fine Feed |
Manual |
| |
|
|
|
|
| 18 |
Weight (Approx) Without Electrical |
330 |
330 |
kg |
