MODEL |
UNIT |
| |
|
|
|
| 1 |
Drilling Capacity (in steel) |
13 |
mm |
| |
|
|
|
| 2 |
Throat (distance Between Centre of
Spindle & Column FACe) |
155 |
mm |
| |
|
|
|
| 3 |
Max. Distance (Nose to Base ) |
550 |
mm |
| |
|
|
|
| 4 |
Max. Distance (Nose to Table) |
300 |
mm |
| |
|
|
|
| 5 |
Spindle Travel |
75 |
mm |
| |
|
|
|
| 6 |
Taper in Spindle |
Solid |
mt |
| |
|
|
|
| 7 |
Size of square Table |
205x205 |
mm |
| |
|
|
|
| 8 |
Working Surface of Table |
205x205 |
mm |
| |
|
|
|
| 9 |
Size of Base |
360x265x65 |
mm |
| |
|
|
|
| 10 |
Working Surface of Base |
210x145 |
mm |
| |
|
|
|
| 11 |
Nos. of Speed |
4 |
8nos |
| |
|
|
|
| 12 |
Speed Range (Motor Rpm-1440) |
500x2825 |
rpm |
| |
|
|
|
| 13 |
Motor Power |
.37 Kw/.5Hp1/2 |
kw/hp |
| |
|
|
|
| 14 |
Column Length |
820 |
mm |
| |
|
|
|
| 15 |
Column Diameter |
47 |
mm |
| |
|
|
|
| 16 |
V-Belt |
A34 |
inch |
| |
|
|
|
| 17 |
Overall/Dimension H x W x T |
840x290x250 |
mm |
| |
|
|
|
| 18 |
Weight (Approx) Without Electrical |
45 |
kg |
| |
|
|
|
| 19 |
Size of Round Table (Optional Std.) |
na |
mm |
| |
|
|
|
| 20 |
Size of Round Base (Optional Std.) |
na |
mm |
