Model |
Model |
| |
|
|
|
|
| 1 |
Drilling Capacity (In Steel) |
25 |
40 |
| |
|
|
|
|
| 2 |
Column Diameter |
87 |
87 |
| |
|
|
|
|
| 3 |
Center of Spindle & Column Face |
255 |
255 |
| |
|
|
|
|
| 4 |
Max. Distance (Nose to Base) |
1050 |
1050 |
| |
|
|
|
|
| 5 |
Max. Distance (Nose to Table) |
650 |
650 |
| |
|
|
|
|
| 6 |
Taper in Spindle |
M. T. - 03 |
M. T. - 04 |
| |
|
|
|
|
| 7 |
Spindle Travel |
170 |
200 |
| |
|
|
|
|
| 8 |
Quill-Dia Meter |
¢63.5 |
¢72 |
| |
|
|
|
|
| 9 |
Nos. of Speed |
08 |
08 |
| |
|
|
|
|
| 10 |
Range of Speed |
73 to 1800 |
73 to 1800 |
| |
|
|
|
|
| 11 |
Table Size |
360 x 360 |
360 x 360 |
| |
|
|
|
|
| 12 |
Base Size (Machined area) |
360 x 280 |
400 x 330 |
| |
|
|
|
|
| 13 |
Overall Base Size |
635x380x
85 |
690x430x
100 |
| |
|
|
|
|
| 14 |
V-Belt Section |
B-51 |
B-55 |
| |
|
|
|
|
| 15 |
Electric motor |
1 - H.P. / 960 rpm |
1.5 - H.P. / 1440 rpm |
| |
|
|
|
|
| 16 |
Wooden Case Size (L X w x H) |
900x500x
1525 |
950x500x
1525 |
| |
|
|
|
|
| 17 |
Weight (Approx) |
220 |
270 |
| |
|
|
|
|
