Model |
| |
|
|
|
|
| 1 |
Drilling Capacity (In Steel) |
25 |
| |
|
|
|
|
| 2 |
Column Diameter |
74 |
| |
|
|
|
|
| 3 |
Center of Spindle & Column Face |
205 |
| |
|
|
|
|
| 4 |
Max. Distance (Nose to Base) |
925 |
| |
|
|
|
|
| 5 |
Max. Distance (Nose to Table) |
650. m / m |
| |
|
|
|
|
| 6 |
Taper in Spindle |
M.T. - 03 |
| |
|
|
|
|
| 7 |
Spindle Travel |
170 |
| |
|
|
|
|
| 8 |
Quill-Dia Meter |
¢63.5 |
| |
|
|
|
|
| 9 |
Nos. of Speed |
08 |
| |
|
|
|
|
| 10 |
Range of speed |
86 to 3360 |
| |
|
|
|
|
| 11 |
Table Size |
270x270 |
| |
|
|
|
|
| 12 |
Base Size (Machined area) |
260x 260 |
| |
|
|
|
|
| 13 |
Overall Base Size |
570x350x75 |
| |
|
|
|
|
| 14 |
V-Belt Section |
B-51 |
| |
|
|
|
|
| 15 |
Electric motor |
1. H / P - 1440 rpm |
| |
|
|
|
|
| 16 |
Wooden Case size (L x W x H) |
1500x630x290 |
| |
|
|
|
|
| 17 |
Weight (Approx) Without Electrical |
140. kgs |
| |
|
|
|
|
|
